Projects
Photos taken on our sites, without staging. Out of discretion we do not name our clients, and labels bearing names have been blurred.
UniFi network rack
Dream Machine Pro gateway, 48-port switch, labelled patch panels and a fibre tray.
Patching rack
Six 24-port panels, white patch cords dressed row by row.
Villa, distribution rack
One switch per use, labelled Wi-Fi, television and sound. UPS units and voltage regulators above the rack.
Fibre distribution frame
Trays labelled by building, dressed patch cords, cables entering from below.
Network and CCTV rack
UniFi gateway and switch, SC fibre tray, Hikvision recorder.
Agri-industrial site
Panels labelled by area, offices, hatchery and labs, fibre uplinks and Cisco switches.
Building management cabinet
Controllers for the air handling units, labelled terminal blocks.
UniFi Dream Machine SE and Pro Max switch
Keystone patching labelled port by port, cords cut to length.
Server room
HPE servers, NAS storage, rack console and switches at the top of the rack.
New building
Network, video surveillance and sound in one rack, during the termination phase.
Ruijie network rack
Three switches, two patching levels, looms held with cable ties.
Villa, network and multiroom audio
UniFi rack with one Sonos amplifier per zone.
Network core
Core chassis, copper and fibre patching to the floors.
Offices, network and IP telephony
HPE switches, Zycoo IP PBX, labelled category 6 panels.
CCTV cabinet
Hikvision recorder, PoE switch for the cameras and a 24-port switch, in a room nearing completion.
Building management cabinet
Power supply, industrial switch and controller modules on DIN rail.
Offices, server and telephony
Dell server, Zycoo IP PBX and APC UPS in the same rack.
Wall cabinet
Sound amplifier and patching in a locked glass-door cabinet.
